Strawberry Containerized Elevated Substrate Cultivation System
Product illustration: images/vegetable/HVC-V08.jpg (Elevated Strawberry Cultivation Tray)
I. Product Overview
The HVC-V08 utilizes a raised substrate cultivation system, where strawberries are grown in suspended cultivation trays – allowing the fruits to hang naturally, ensuring excellent ventilation and a clean, soil-free growing environment. When combined with precise water and fertilizer management as well as supplemental lighting, this system enables the stable production and continuous harvesting of off-season strawberries throughout the winter.
II. Core Competitive Advantages
● Hanging fruits: The fruit bunches hang naturally without touching the substrate, ensuring high cleanliness and a high marketability rate.
● Precision irrigation and fertilization: drip irrigation per plant combined with return fluid monitoring – ensuring high fertilizer utilization efficiency.
● Bees-friendly pollination: Bees can be introduced into the hive; the rate of abnormal fruit production is low (users are required to configure the hive themselves).
● Continuous harvesting: A single planting enables batch harvesting over an extended period.
● period.
III. Typical Technical Specifications
project | parameter |
outline dimension | 12000 × 2438 × 2896 mm (40 feet) |
Cultivation Method | Elevated substrate tank (coconut coir/rock wool optional) |
Planting density | 1200–1800 plants |
Temperature control range | 18–24 ℃（±1 ℃） |
relative humidity | 60%–75% RH |
beam | LED 220–400 μmol/(m²·s) |
EC / pH | 1.0–1.4 mS/cm ｜ 5.8–6.2 |
installed power | 13–18 kW |
source | 380 V / 50 Hz Three-phase |
IV. System Configuration
Elevated cultivation troughs and support frames; substrate and drip irrigation systems; return liquid collection and disinfection; automatic EC/pH-based fertilization system; full-spectrum LED supplemental lighting; constant-temperature fresh air and dehumidification unit; CO₂ supplementation module (optional); intelligent control cabinet.
V. Applicable Varieties
Sun-neutral strawberry varieties (Four Seasons Strawberry) and conventional short-day strawberry varieties.
VI.适用场景
Off-season strawberry picking farm, direct strawberry supply from premium supermarkets, and family-friendly agricultural tourism activities.
VII. Delivery and Installation
Delivered as a complete unit; commissioning is completed within 4–5 working days after on-site hoisting and power connection; guidance on substrate filling, planting, and pollination management is provided.
VIII. After-Sales Service
12-month comprehensive warranty; includes seasonal cultivation technical support, fertilizer formulation upgrades, and remote maintenance services.
