Small Tomato Substrate Cultivation Container
Product illustration: images/vegetable/HVC-V10.jpg (Substrate trellis-based fruit and vegetable cultivation area)
I. Product Overview
The HVC-V10 is designed for substrate cultivation of fruits and vegetables, such as cherry tomatoes, and employs a combination of trellis-based three-dimensional planting system and precision drip irrigation, complemented by CO₂ supplementation and a high-light lighting regimen, enabling continuous long-season fruit and vegetable production within a container-based environment.
II. Core Competitive Advantages
● Vertical trellis system: Maximizes the use of the net height within each container, enabling a high planting density per container.
● Precision irrigation: targeted water and fertilizer application per plant, with return water collection and monitoring – saving water and fertilizer.
● CO₂ supplementation: Increased concentration enhances photosynthesis, leading to significant improvements in fruit sweetness and yield.
● Long-term harvesting: A single planting allows for continuous harvesting over several months, resulting in a high input-output ratio.
III. Typical Technical Specifications
project | parameter |
outline dimension | 12000 × 2438 × 2896 mm (40 feet) |
Cultivation Method | Substrate bagging + trellis training |
Planting density | 300–500 plants |
Temperature control range | 20–26 ℃（±1 ℃） |
relative humidity | 60%–75% RH |
beam | LED 300–500 μmol/(m²·s) |
EC / pH | 2.0–3.5 mS/cm ｜ 5.8–6.5 |
CO₂ concentration | 800–1200 ppm (Optional) |
installed power | 14–20 kW |
source | 380 V / 50 Hz Three-phase |
IV. System Configuration
Substrate cultivation troughs and drainage system; trellis support frames and suspension ropes; drip irrigation per plant and return liquid disinfection; automatic EC/pH-based fertilization system; high-power full-spectrum LED supplemental lighting; CO₂ supplementation and concentration monitoring; constant-temperature fresh air supply and dehumidification unit; intelligent control cabinet.
V. Applicable Varieties
Cherry tomatoes (also known as small tomatoes), cluster-grown tomatoes and cucumbers, bell peppers, and other fruits and vegetables.
VI.适用场景
High-end direct-supply tomato production base, picking experience garden, and plant factory fruit and vegetable demonstration project.
VII. Delivery and Installation
Delivered as a complete shipment; commissioning is completed within 4–5 working days after on-site hoisting and power connection; guidance on planting, trellising, pruning, and pollination management will be provided.
VIII. After-Sales Service
12-month overall product warranty; provides long-term cultivation technical support, formula optimization, and remote operation and maintenance services.
